Notice[edit | edit source]
This will be the instruction guide for the HID Liberation Device.
Firmware[edit | edit source]
Firmware source code: https://github.com/BathroomEpiphanies/AVR-Keyboard
Compiling[edit | edit source]
Linux/Windows[edit | edit source]
You need to select the correct BOARD and LAYOUT variables in the Makefile
BOARD = hib_liber LAYOUT = ansi_iso_jis MCU = atmega32u4 F_CPU = 16000000 B_LOADER = \"jmp\ 0x7000\"
Then run the make command in a terminal. Always run a make clean first.
make clean; make
Flashing the controller[edit | edit source]
Linux/Windows[edit | edit source]
dfu-programmer atmega32u4 erase dfu-programmer atmega32u4 flash avr_keyboard.hex dfu-programmer atmega32u4 start
Schematic[edit | edit source]
