File:Alps SKCM -- tactile leaf cross section.gif
From Deskthority Wiki
Jump to navigationJump to search
No higher resolution available.
Alps_SKCM_--_tactile_leaf_cross_section.gif (480 × 270 pixels, file size: 1.04 MB, MIME type: image/gif, looped, 33 frames, 2.0 s)
| Description | A cutaway view of the inside of an Alps SKCM cream damped switch. Note how the tactile leaf (left) stays pressed against the outer housing wall during operation. |
|---|---|
| Source | Own work |
| Date | 2016-02-12 |
| Author | Nick Bair |
| Licence | Public Domain |
