Alps_SKCM_--_click_leaf_cross_section.gif (480 × 270 pixels, file size: 1.33 MB, MIME type: image/gif, looped, 45 frames, 2.7 s)

Description A cutaway view of the inside of a click-modified Alps SKCM cream damped switch. Note how the click leaf (left) pulls away from the outer housing wall before snapping back into place.
Source Own work
Date 2016-02-12
Author Nick Bair
Licence Public Domain
